13X APG Molecular sieve

Guangdong Xintao 13X APG molecular sieve is specially designed to co-absorb CO2 and H2O for air cryo-separation industry. It has larger capacity and faster adsorption speed for removal of CO2 and H2O to prevent the bed gelation.

Model13X APG
ColorLight gray
Nominal pore diameter10 angstroms
ShapeSphere
Pellet
Diameter (mm) 1.7-2.5 (8*12mesh)3.0-5.0 (4*8 mesh)1.6 (1/16 inch)3.2 (1/8 inch)
Size ratio up to grade (%) ≥98≥98≥98≥98
Bulk density (g/ml)≥0.67≥0.65≥0.63≥0.62
Wear ratio (%)≤0.20≤0.20≤0.40≤0.40
Crushing strength (N)≥25/piece≥75/piece≥25/piece≥60/piece
Static H2O adsorption (%)≥27≥27≥27≥27
Static CO2 adsorption (%)≥18≥18≥18≥18
Water content (%)≤1.5≤1.5≤1.5≤1.5
Typical Chemical FormulaNa2O . Al2O3 . 2.45SIO2 . 6.0H2O (SiO2 : Al2O3 ≈2.6-3.0)
Typical ApplicationRemoval of CO2 and H2O for air cryo-separation application
Warranty

a)By National Standard HG-T_2690-2012

b)Offer lifetime consultation on problems occurred

Regeneration:

Guangdong Xintao Molecular Sieve Type 13X APG can be regenerated by either heating in the case of thermal swing processes; or by lowering the pressure in the case of pressure swing processes.

To remove moisture from a 13X APG molecular sieve, a temperature of 250-300°C is required. A properly regenerated molecular sieve can give moisture dew points below -100°C, or mercaptans or CO2 levels below 2ppm.

The outlet concentrations on a pressure swing process will depend on the gas present, and on the conditions of the process

Size:

13X APG- Zeolite are available in beads of 1-2 mm(10x18 mesh), 2-3 mm(8x12 mesh), 2.5-5 mm(4x8 mesh) and as powder, and in pellet 1.6mm, 3.2mm.

Attention:

To avoid damp and pre-adsorption of organic before running, or must to be reactivated.
